McCloskey TS4065 Tracked Stacker

Stockpile Height:
7.88m
Weight:
10,500kg
Engine:
CAT C2.2
Overview
The McCloskey TS4065 sets the standard for high capacity, high mobility stackers.

It comes with an impressive array of features, including a large hopper, full-length guarding, an easily accessible engine bay, an impact section under the feed boot and an adjustable feed boot height.

As is the case with all McCloskey stackers, the TS4065 features a setback design for maximum stockpiling.

At 65’ long, this stacker is the entry point for McCloskey tracked stackers, which are also available in 80’, 100’ and custom lengths.

Features

CAT C2.2 63Hp
1000mm x 19810mm main conveyor belt.
Large hopper delivers high volume capabilities.
Heavy duty impact bed.
Hydraulically adjustable discharge height.
Hydraulically adjustable feed in height.
For maximum mobility, tracks allow the stacker to be easily moved on its own.
Fast on-site setup time (5 minutes).

Tech Specs

Engine
CAT C2.2 63Hp
Transport Height
2.5m
Transport Length
12.1m
Transport Width
2.34m
Weight
10,500kg
Stockpile Height
7.88m
Stockpile Capacity
902m³
Production
510TPH
Download Full Specs
