McCloskey I4CR Impact Crusher

Impactor Size:
1050mm x 1125mm
Weight:
41,000kg
Engine:
CAT C9.3B
Overview
The I4C is in a class of its own, bringing the productivity of a 1125mm impactor to a compact footprint for maximum power and manoeuvrability.

The crusher's design has ease of access in mind, with an excellent layout for operation, maintenance and service. Advanced clutch technology delivers reduced fuel consumption, and less maintenance while increasing safety and productivity.

With its simplified controls and efficient hydraulics, the I4C heavy duty track mounted crusher is sure to make an impact across a variety of materials and applications.

Features

1050mm diameter x 1125mm wide Impactor.
CAT C9.3B 375Hp engine.
Integrated hydraulic folding stockpiling conveyors.
I-beam plate fabricated chassis construction.
Open chassis design for ease of maintenance.
Fast setup time.
Apron adjustment to suit either secondary or primary crushing.
Single deck recirculation screen.
Swing out radial return conveyor.

Tech Specs

Engine
CAT C9.3B 375Hp
Transport Height
3.2m
Transport Length
15.8m
Transport Width
3m
Weight
41,000kg
Impact Rotor
1050mm x 1125mm
Stockpile Height Fines Conveyor
3.01m
Stockpile Height Side Conveyor
2.75m
Download Full Specs
